- Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
- Rugged urethane molded case protects the module from rough handling and harsh conditions
- Features internal temperature compensation from 0º C to 50º C for full-accuracy performance
- Includes NIST-traceable calibration certificate
- Module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source
- Certified by CSA: I.S. Class I, Div 1, Groups A-D T4, Ta = 0 °C to 50 °C
- ATEX II 1G EEx ia IIC T4 Compliant.
- One year warranty
| Specifications | | Range | | | Resolution | | | Reference Uncertainty (23 ± 3° C) | | | Total¹ Uncertainty 1 year | | | High Side Media² | | | Low Side Media² | | | Note | | 1) | Total uncertainty, one year for temperature range 0° C + 50° C. | | Total uncertainty, 1.0% of full span for temperature range - 10° C to 0° C. | | Compensated temperature range is 15° C to 35° C.
| | 2) | "Dry" indicates dry air or non-corrosive gas as compatible media. | | "316 SS" indicates media compatible with Type 316 Stainless Steel. | | "C276" indicates media compatible with Hastelloy C276. |
|
|
|
|
